5240-547
9 TON ELECTRIC LOG SPLITTER
8
DO NOT ADJUST THE MAX PRESSURE LIMITING SCREW!
Max pressure was set before the log
splitter left the factory and the max
pressure limiting screw is sealed with glue
to ensure the log splitter works under
pressure no more than 9 tons. The setting
was done by a qualified mechanic with
professional instruments.
Unauthorized resetting will cause the
hydraulic pump to fail to output enough
splitting pressure or RESULT IN SERIOUS
INJURY AS WELL AS DAMAGE TO THE
MACHINE .
15. Max Pressure Limiting Screw
WIRING DIAGRAM PLUMBING DIAGRAM
