12
TM
3.6 ASSEMBLING THE MULCHING PLUG
1. Remove the grass bag.
2. Push the plastic mulching plug into the discharge chute until it is locked in
place.
3. Release the ap to close the rear discharge cover.
Mulching Plug
Rear Discharge
Cover
Side Discharge Chute
Side Discharge
Cover
