Benchmark HCM400 User Manual

2620-176
4 CU FT ELECTRIC CEMENT MIXER
12
OPERATING INSTRUCTIONS
DRUM TILTING
The spring-loaded tipping bar with locking lugs provides an easy positive control of
the drum which can be locked in the mix, discharge and stored position.
The drum is locked in position by lugs on the self-locating tipping bar/wheel which
engage into the locking plate on the mixer frame. To tilt the drum, withdrawn the
tipping bar to dis-engage the locking lugs. This then allows the tipping bar and drum
to be turned in the same direction.
To retain the drum in position, aligning the lugs with the slots, release the tipping bar
a little while retaining the drum. Rotate the tipping bar until the locking lugs engage
into the locking plate on the mixer frame.
LOADING/MIXING POSITION
For Mortar For Concrete EMPTYING
POSITION
STORAGE
POSITION
LOADING
Completely unwind the extension cord. Connect it to the concrete mixer first
before plugging in power supply.
Always start the mixer before loading the drum. Loading the drum
with drum rotating.
Do not throw material into the mixer to avoid sticking firmly to the back of the
drum. Trickle it steadily over the ram.
NOTE: A built-in thermal protector is arranged in the motor to prevent it from
overheating. The thermal protector restores automatically when the motor
cools down.
