BENDIX AD-9 User Manual

8
MAINTENANCE KITS
Kit Part
Number
Service New (S)
or Reman
Exchange (RX)
Purge
Valve Type Heater
Connector
Color Kit Description Illustration
107695 S – – –
Complete Mounting Bracket Kit - Contains the
upper and lower brackets as well as the necessary
mounting hardware.
A
5002080 S – – –
Mounting Kit B
5009610 S – – –
107799 S – – –
End Cover Check Valve Assembly Replacement -
3/4 inch thread size.
C
107800N S – – –
End Cover Check Valve Assembly Replacement -
1/2 inch thread size.
5005037 S Hard Seat – –
Purge Valve Housing Maintenance Kit - Contains
the parts necessary to rebuild the air portion of
the purge valve housing and does not include the
heater and thermostat.
D
5005893 S Soft Seat – –
K041395 S – – – Universal Check Valve Kit E
5003838 S – – – Exhaust Cover Kit F
5004224N S – – – Silencer Kit G
107796 S – – –
Desiccant Cartridge Replacement Kit - Contains
the parts necessary to change the desiccant
cartridge only. Non-IPC Air Dryer
H
107794X RX – – –
K028830 S – – –
Desiccant Cartridge Replacement Kit - Contains
the parts necessary to change the desiccant
cartridge only. IPC Air Dryer
109960 S – – –
Makeup Line Kit
I5000457 S – – –
109961 S – – – Adaptor Kit
800405 S Soft Seat 12V-75W White
Purge Valve Housing Assembly
(w/heater and thermostat)
J
5004338 S Soft Seat 24V-75W Gray
5004341X RX Soft Seat 12V-75W White
5004342X RX Soft Seat 24V-75W Gray
5004479 S Hard Seat 12V-75W White
5004480 S Hard Seat 24V-75W Gray
5004381 S Hard Seat 24V-100W Yellow
5004339 S DLU 12V-75W White
5004340 S DLU 24V-75W Gray
5006580 S DLU 24V-100W Yellow
See Catalog
BW1114
S and RX – – – End Cover Replacement K
109578 S – 12V-75W White
Heater and Thermostat Kit L
109579 S – 24V-75W Gray
5002595 S – 24V-100W Yellow
109871N S – – – Heater Electrical Splicing Kit M
113209 S – – – Universal Mounting Plate N
