2
RE-6NC
™
Valve
FIGURE 3 - RE-6
™
& RE-6NC
™
RELAY VALVES SYSTEM CONFIGURATION
RE-6NC
™
RELAY VALVE DOLLY SYSTEM CONFIGURATION
Slack Adjuster
Service Brake Chamber
Reservoir
Single Check
Valve
R-12P
™
Valve
SV-4
™
Valve
Bulkhead
Drain
Valve
PR-3
™
Valve
Trailer Gladhand
Single Check
Valve
RE-6
™
RELAY VALVE DOLLY SYSTEM CONFIGURATION
Bulkhead
SV-4
™
Valve
RE-6
™
Valve
Slack Adjuster
Service Brake Chamber
Drain
Valve
Reservoir
Single Check
Valve
R-12P
™
Valve
Trailer Gladhand
CONTROL LINE
FRONT
SUPPLY LINE
CONTROL LINE
FRONT
SUPPLY LINE
