4.3 TABLE OF BENDIX
®
WINGMAN
®
ADVANCED
™
DIAGNOSTIC TROUBLE CODES (DTCs)
NOTE: FLR10 RADAR SENSORS USE DIFFERENT DTCS — SEE SD-61-4962.
Refer to column one for the DTC(s) found and determine the Service Action Code(s) to take. See Tables 6A and 6B below:
Table of Diagnostic Trouble Codes (DTCs), Causes and Recommended Actions for FLR20 Radars
DTC SPN FMI Description
Go to the Service
Action Code List
in Table 6B
1-2 886 14 Internal radar sensor error A
3 886 14 Antenna is dirty or partially blocked C
4 886 4 Battery voltage too low B
5 886 3 Battery voltage too high B
6-10 886 14 Internal radar sensor error A
11 886 14 J1939 wiring harness error or other device DTC K
12-15 886 14 Internal radar sensor error A
16 886 14 Antenna is dirty or partially blocked C
17-27 886 14 Internal radar sensor error A
29 886 14 J1939 Signal Error: Missing AEBS2 message M
30 886 14 J1939 Signal Error: Missing CCVS message M
31 886 14 J1939 Signal Error: Missing CVW message M
32 886 14 J1939 Signal Error: Missing EBC1 message M
33 886 14 J1939 Signal Error: Missing EBC2 message M
34 886 14 J1939 Signal Error: Missing EBC5 message M
35 886 14 J1939 Signal Error: Missing EEC1 message M
36 886 14 J1939 Signal Error: Missing EEC2 message M
37 886 14 J1939 Signal Error: Missing ERC1_DR message M
38 886 14 J1939 Signal Error: Missing ERC1_XR message M
41 886 14 J1939 Signal Error: Missing TD message M
42 886 14 J1939 Signal Error: Missing VDC2 message M
43 886 14 J1939 Signal Error: Missing VDHR message M
44 886 14 J1939 Signal Error: Missing EBC3 message M
45 886 14 Internal radar sensor error A
46 886 7 Radar sensor is misaligned D
47-77 886 14 Internal radar sensor error A
78 886 14 Bendix ABS J1939 Proprietary message signal missing or error state E
79-81 886 14 Internal radar sensor error A
82 3839 16 Adaptive Cruise Control braking overuse F
83 898 13
J1939 Signal ACC1 Engine not properly confi gured for Wingman Advanced
G
84-85 886 14 Internal radar sensor error A
86 886 14 Confi guration mismatch between brake controller and radar sensor H
87 886 14 J1939 Signal Error: Missing VDC1 message M
88 886 14 CMT braking overuse J
92 886 14 J1939 Signal Error: Invalid CCVS1 wheel speed P
93 886 14 J1939 Signal Error: Error in CCVS1 wheel speed N
94 886 14 J1939 Signal Error: Not available CCVS1 wheel speed O
95 886 14 J1939 Signal Error: Invalid CCVS1 CC speed P
TABLE 6A - REFER TO COLUMN ONE FOR EACH DTC CODE FOUND AND FIND ITS SERVICE ACTION CODE.
