BENE LEVEL - Assembly - LEVEL (Crank); Mount the Cantilever Leg; Tighten Screws and Mount Covers

11
3 4
8x
D990429
GWSR-ZKIS-VZ-M6/40
2a
3a
Installer l’embase de piètement
(fixer les vis avec 10 Nm maxi.)
Mount the cantilever leg (secure
with screws with max. 10 Nm)
Fußausleger montieren
(Schrauben fixieren max. 10 Nm)
Resserrer les vis à la main (max. 7,5 Nm)
et monter les caches.
Tighten screws by hand (with no more than 7.5 Nm)
and mount covers
Schrauben händisch nachziehen (max. 7,5 Nm)
und Abdeckungen montieren
MONTAGE LEVEL (MANIVELLE)
ASSEMBLY LEVEL (CRANK)
MONTAGE LEVEL (KURBEL)
