BENE LEVEL - Option - T-Panel Installation; Install Middle Adapter (1401 mm+); Secure Adapter to T-Panel Multi

26
1 2
3 3a
6x
D990465
GWSR-LKIS-VZ-M8/16
6x
D990689
USCH-VZ-FM8-DIN9021
Écart de 2 mm
Écart de 20 mm
2-mm gap
20-mm gap
2 mm Spalt
20 mm Spalt
OPTION. MONTAGE T-PANEL
Adaptateur central à partir de 1401 mm.
Fixer les adaptateurs au T-Panel Multi.
OPTION. T-PANEL INSTALLATION
Middle adapter starting at 1401 mm.
Secure the adapter to the T-Panel Multi.
OPTION. MONTAGE T-PANEL
Mittlerer Adapter ab 1401 mm.
Adapter an T-Panel Multi fixieren.
