Benelli 2014 BN600 User Manual

- II -
HOW TO USE THIS MANUAL
This manual is a practical reference guide that is both easy to handle and use for mechanics. The explanations of all of the procedures
for installing, removing, disassembling, • tting, repairing and checking, are organised in sequence, one step at a time.
1. Each chapter is divided into sections. The top part of each page contains the title of the current section.
2. To help with the identi• cation of parts and to make the different processes clearer, exploded drawings are provided at the start
of each section dealing with the removal or disassembly of parts.
3. The sequence of operations is listed on the exploded drawing, and numbered progressively. Each number refers to a step in the
disassembly process.
4. Parts needed lubricating or replacing are marked by symbols. See the "SYMBOLS" section.
5. The exploded drawing is accompanied by a table with instructions for the intervention. These state the order of operations, the
name of the parts, any notes for the job, etc.
6. Interventions requiring any other information (e.g., special tools and technical data) are described in sequence.
pecial tools and tec
pecial tools and tec

Benelli 2014 BN600 Specifications

General

Displacement	600 cc
Bore x Stroke	65 x 45.2 mm
Compression Ratio	11.5:1
Max Power	82 hp (60 kW) @ 11, 500 rpm
Ignition	Digital
Transmission	6-speed
Final Drive	Chain
Front Tire	120/70-ZR17
Rear Tire	180/55-ZR17
Width	800 mm
Seat Height	800 mm
Ground Clearance	150 mm
Fuel Capacity	15 liters
Dry Weight	208 kg
Engine Type	Inline 4-cylinder, 4-stroke, liquid-cooled, DOHC
Fuel System	Electronic fuel injection
Frame	Steel trestle
Front Suspension	Upside-down forks, 50mm
Rear Suspension	Swingarm with monoshock
Front Brake	Dual 320mm discs, 4-piston calipers
Rear Brake	Single 240mm disc
Length	1480 mm
Wheelbase	1480 mm
