BENETEAU 331 - Page 53

BENETEAU 331 Page 53 of 73
Jan. 10, 2003
rev 02
LAY OUT OF THE CONDUITS
REF DESCRIPTION
1 Extra Conduit from Starboard side to Port side
2 Conduit 12V Panel to Transom
3 Conduit from Panel to Mast
4 Conduit From Panel to Fwd Cabin
5 Conduit from Pump House to Galley
Passage in the hull liner
Passage in the deck liner
1
12 3 4
5
1
12 3 4
5
