BENETEAU 331 Page 56 of 73
Jan. 10, 2003
rev 02
XIX) EMERGENCY STEERING SYSTEM
Your boat is provided with an emergency tiller for use if there is a failure in the wheel steering system. The
access cover on the cockpit floor above the rudder must be kept clear at all times.
Check at least once a year that the steering cables are properly tightened and lubricated.
To use the emergency tiller, remove the access cover; insert the tiller into the socket on the rudderstock. You
may remove the steering wheel while using the tiller, to improve the tiller handle clearance.
REF DESCRIPTION
1 Emergency Tiller
2 Cap to Get to the Rudder Stock
3 Rudder Stock
4 Steering Cable
5 Quadrant
6 Rudder Shaft Bearing
7 Split Sleeve – up to hull #30
8 Washer – up to hull #30
