13) LED DIAGNOSTICS
The red LED DL1 indicates the activation of inputs according to
the legend hereunder:
The green LED DL2 indicates the movement direction of the motor
and the status of the gate according to the legend hereunder:
The Unit is Powered flashing slowly OPENING 1 blinking per second
STOP on with fixed light CLOSING
2 more than 1 blinking per sec.
PHOT rapid flashing Open gate without TCA on with fixed light
SWO 1 flash with 2-second interval Open gate with TCA rapid flash
SWC
2 flashes with 2-second interval
Closed gate LED off
14) FUSES
CP.BULL5 ARC 230Vac: F2 = T100mA F3= F6,3A
CP.BULL5 ARC 115Vac: F2 = T200mA F3 = F10A
