1) IRI.KPAD
1.1) DESCRIPTION
Programmable wireless digital keypad.
It allows to carry out the control of automatic systems for gates and similar systems,
with no need to lay any cables.
IRI.KPAD is powered by one 3,6V 1/2 AA battery and transmits the radiofrequency
control to another transmitter in a similar way. The main characteristics are:
• LED retro light.
• Compatible with all Benincà radio receiver models with 433.92 MHz operating
frequency.
• Type of code: programmable code, rolling- code and ARC (advanced rolling-code).
• 1 to 9 digit code composition.
• 0 to 9 keys plus # or to confirm.
• Possible setting of access password, scalar code and elimination of single codes.
• Possible enabling of the # key for code repetition.
• Indication of down battery and buzzer for acoustic indications.
1.2) TECHNICAL DATA
Power supply One 3,6V 1/2AA lithium battery (Li) 1400 mAh
Range without obstacles
100m
Operating frequency 433,92 MHz
Operating temperature -20°C / +70°C
Number of storable codes
254
Protection level IP55
Overall dimensions see Fig.1
1.3) WALL INSTALLATION (FIG. 1)
WARNING: As the various programming phases require an access to the radio receiver of
the system, it is advisable to fix the keypad to wall only after programming all functions.
The IP55 protection level permits to use the keypad also on walls that are not
protected against weather agents.
It is however advisable, whenever possible, to apply the system on a protected wall.
In any case, it is mandatory to apply the G gasket between wall and container.
(FIG.2-3)
1. Open the container by loosening the screw H. Screw H is a 3.5 mm TORX security
screw, supplied with a special screwdriver.
2. Apply the bottom of the container to wall by using either the two plugs T and
the two screws C, if a masonry support is provided, or self-tapering screws, if
a metal support of provided: in any case, use a fixing suitable to the support.
3. Close the container.
