The radio receiver in this product is compatible only with ARC (Advanced Rolling Code) transmitters which, thanks to 28 bit coding, guarantee superior
anti-copying security.
1) DESCRIPTION AND INTENDED USE
Automation for balanced sectional doors available in two versions: JACK24.50 and JACK24.80.
Both models are equipped with an electronic limit switch (Absolute encoder), LED courtesy light and preparation for battery operation, using two 12V
batteries, art. JACK.24 CB
JACK available of an unlocking system for manual movement of the door in the event of a power cut.
Accessories are also available to install automation on the shafts with different dimensions to the standard 1" (25,4mm).
The product is equipped with an ESA SYSTEM to reduce consumption in StandBy, see ESA logic in paragraph 9.2.
Figure 2 lists the elements inside the packaging:
JACK Packaging
A Fastening bracket
B 1 - Unlocking pendant
2 - Locking pendant
3 - Hex head screw M8
4 - Nut M8
5 - Washer
6 - Tabs
C JACK gearmotor
2) TECHNICAL DATA
Figure 1 indicates the valid dimensions for both models.
JACK 24.50 JACK 24.80
Mains power supply 230 Vac (50/60Hz) o 115Vac (50/60Hz)
Motor power supply 24 Vdc
Control unit CP.JACK
Maximum power consumption 3,3 A
Maximum torque 50 Nm 80 Nm
Output speed 34 rpm
0.356 m/s with drum diameter 100
0.534 m/s with drum diameter 150
22 rpm
0.230 m/s with drum diameter 100
0.345 m/s with drum diameter 150
Shaft bore 1" (25,4mm)
Maximum door surface 20 m
2
35 m
2
Max. number output shaft rotations 20
Operating temperature -20°C /+50°C
Operating cycle* 50 cycles/hour at 25°C
25 cycles/hour at 50°C
30 cycles/hour at 25°C
15 cycles/hour at 50°C
Number of transmitters saved 512 ARC
Protection degree IP40
Lubrication Grease
Weight 7,590 Kg 7,690 Kg
*Referred to sectional balanced door 6m x 3m
Check the maximum height of the door is within the actuator field of use, to calculate compatibility between the height
of the door and number of max rotations of the gearmotor, refer to the following formula:
Maximum door height = 3.142 x d x 20
d = diameter of rope winding drum
