8) CP.JACK CONTROL UNIT
The follows table shows the electrical connections in Fig. 11:
Terminals Function Descrizione
L-N-GND Power supply Mains input 100÷250Vac 50/60Hz
MOT Motor Pre-cabled motor connection: 24Vdc.
ENC ENCODER Absolute encoder quick connector
ANT-SHIELD Antenna
Built-in radio transmitter card antenna connection (ANT-signal/SHIELD-screen).
SIS SYNC Rapid connection for SYS synchronisation (optional)
COM Common Inputs Common for all control inputs.
P.P Step-by-Step Step-by-Step button input (N.O. contact) .
STOP STOP Button input STOP (N.C. contact).
PHOT Photocell Photocell input active in opening and closing (N.C. contact).
OPEN Opens Open button input (N.O. contact), you can connect a timer for time slot openings.
CLOSE Close Close button input (N.O. contact). .
BAR Sensitive edge
Input, safety edge. A 8.2 Kohm resistance is pre-installed on the terminals.
Safety edge of the resistive type, 8K2: connect the edge to the terminals by eliminating the pre-installed
resistance, as shown in Figure 14.
Safety edge of the mechanical type: connect the edge in series to the resistance, as shown in Figure 15.
When the safety edge is activated, the door movement is stopped and reversed for around 3sec.
+ 24V - 24 Vdc Power supply output accessories 24Vdc/500 mA max.
BLINK Flashing 24Vdc output 15W max. for connection to the flashing light.
AUX AUX 1 Auxiliary output Output with N.O. contact configurable by AUX1 operating logic
+ BAT-BAT Batteries
Terminal input for connection of the back-up batteries (accessory).
Remove the cover in the event of installation.
9) PARAMETERS, LOGIC AND SPECIAL FUNCTIONS
The following table describes the individual functions available in the control unit.
9.1) PARAMETERS (PAR)
MENU FUNCTION MIN-MAX-(Default) MEMO
TCA
Automatic closure time Active only with “TCA”=ON logic.
At the end of the time set, the control unit commands a closure manoeuvre.
1-240-(40s)
tped
It adjusts the opening percentage of the motor controlled by the transmitter with the PED function
(pedestrian function). The value is expressed as a percentage (99% complete opening of the door).
1-99-(50)
sair
It adjusts the partial opening space controlled by the transmitter if saved with the SAIR radio function.
TCA automatic closure has no effect on partial opening.
Partial opening can take place only if the door is completely closed.
Value expressed as a percentage.
1-10 (3)
fsto
It adjusts motor opening speed (standard speed before the slowing phase).
50-99 (99)
fstc
It adjusts motor opening speed (standard speed before the slowing phase).
50-99 (99)
sldo
It adjusts the motor speed during the opening slowing phase* 10-50 (25)
sldc
It adjusts the motor during the closing slowing phase*. 10-50 (25)
tsmo
It sets the start point of the slowing phase in opening.
The value is expressed as a percentage on the entire stroke.
1-99-(20)
tsmc
It sets the start point of the slowing phase in closure.
The value is expressed as a percentage on the entire stroke.
1-99-(20)
PMO
It adjusts the motor torque during the opening phase*. 1-99-(20)
PMC
It adjusts the motor torque during the closure phase*. 1-99-(20)
PSO
It adjusts the motor torque during the opening slowing phase*. 1-99-(30)
PSC
It adjusts the motor torque during the closing slowing phase*. 1-99-(30)
tls
Activation time of the led courtesy light (integrated in the control unit) or the AUX1 contact, if the
AUX1 parameter is set to 2. Value expressed in seconds. On each manoeuvre, the light remains
on for the time set. The service light (on), after pressing one of the 3 buttons of the control unit,
turns off and returns to normal operation after 1 and a half minutes.
1-240 (60)
spin
It sets a short inversion once the closure limit switch point has been reached. It may be useful
to facilitate the manual manoeuvre.
0-20 (3)
aux1
Select the operating mode of the auxiliary output 1 (Free Contact N.O.)
0: Door open light, contact closed with door open, open with door closed, intermittent during
the manoeuvre (Fig. 12)
1: Second radio channel of the receiver incorporated
2: Courtesy light, the duration of the contact closure is adjustable by the TLS parameter (Fig.13)
3: Zone light, it is on if the door is open
0-3-(0)
