16
spn
The pick-up function with ENC:OFF logics is activated or deactivated.
On: the function is enabled. The first two seconds of operation are carried out at maximum torque.
With ENC:ON logics, pick-up is automatically adjusted by the control unit.
(OFF)
htr
The Operator function is enabled or disabled.
On: Operator function enabled.
During operation, the PP/CLOSE push-buttons must be kept pressed.
Off: Automatic/semiautomatic operation.
(OFF)
OPCL
PP input as OPEN are enabled or disabled.
On: PP input is enabled as OPEN.
Off: PP are enabled with their function.
(OFF)
IBCA
During the TCA phase, the PP and transmitters controls are enabled or disabled.
On: PP and TX controls are disabled.
Off: PP and TX controls are enabled.
(OFF)
ENC
The Encoder is enabled or disabled.
On: Enabled encoder.
Off: Disabled encoder (to be used with ZED series motors that are not equipped with built-in Encoder).
NB: The Encoder can be possibly reset (from OFF to ON). A new self-calibration procedure is required
(AUTO menu).
(ON)
PHTo
The operating mode of the PHOT input is selected.
On: PHOT input is activated in both opening and closing.
In the opening phase: when the contact is opened, the motor stops. When the photocell is released,
the motor restarts with an opening movement.
In the closing phase: when the contact is opened, the motor stops. When the photocell is released, the
motor inverts its movement direction (opens).
Off: PHOT input is activated only in the closing phase.
In the closing phase: when the contact is opened, the motor stops and the movement direction is
immediately reversed (opens).
(OFF)
rem
The remote storage of the radio transmitter codes is enabled or disabled (see par. REMOTE LEAR-
NING).
On: Enabled remote storage
Off: Disabled remote storage.
(ON)
5.3) RADIO (RAD)
MENU FUNZIONE
PP
By selecting this function, the receiver awaits (Push) for a transmitter code to be assigned to the step-by-step function.
Press the transmitter key to be assigned to this function.
If the code is valid, it is stored in memory and OK appears.
If the code is not valid, the wording Err is displayed.
2Ch
With AUX:1 parameter, the radio channel II function to terminals 19/20 is activated.
With AUX:0 e AUX:2 parameter, the service light is activated according to the time preset by TLS parameter.
By selecting this function, the receiver awaits (Push) the pressure of the key to be matched with that function.
If the code is valid, the same is memorised and the OK message is displayed.
If the code is not valid, the Err message is displayed.
CLR
By selecting this function, the receiver awaits (Push) for a transmitter code to be erased from memory.
If the code is valid, it is erase and OK appears.
If the code is not valid or is not in memory, the wording Err is displayed.
RTR
Completely erase the receiver memory. Confirmation of operation is required.
5.4) CYCLES NUMBER (NMAN)
Displays the number of complete cycles (open+close) carried out by the automation.
When the <PG> button is pressed for the first time, it displays the first 4 figures, the second time it shows the last 4. Example <PG> 0012 >>>
<PG> 3456: made 123.456 cycles.
5.5) MAINTENANCE CYCLES (MACI)
This function enables to activate the maintenance request notice after a number of manoeuvres determined by the installer.
To activate and select the number of manoeuvres, proceed as follows:
Press button <PG>, the display will show OFF, which indicated that the function is disabled (default value).
With the buttons <+> and <-> select one of the numeric values proposed (from OFF to 100). The values are intended as hundreds of cycles of ma-
noeuvres (for example: the value 50 indicates 5000 manoeuvres).
Press the OK button to activate the function. The display will show the message PROG.
The maintenance request is indicated to the user by keeping the indicator lamp lit up for other 10 sec after the conclusion of the opening or closing
operation.
The warning of maintenance required is indicated to the user through the flashing of the courtesy light LEDs during the opening and closing phases.
5.6) RESET (RES)
RESET of the control unit. ATTENTION!: Returns the control unit to the default values.
Pressing the <PG> button for the first time causes blinking of the letters RES, pressing the <PG> button again resets the control unit. Note: The
transmitters are not erased from the receiver nor is the access password.
