6
ASSEMBLY
An ordinary 1/2” diameter garden hose of min. 5m and max. 25m is suitable. Make sure
that the hose is not damaged in any way and does not leak.
NOTE: Before connecting the garden hose to the machine, let the water run through the hose
to rinse out any sediment.
NOTE: The Inlet Filter (6A) must always be fitted in the Water Inlet to filter out sand, limestone
and other impurities as these will damage the pump valves.
CAUTION: Failure to fit the filter will invalidate the guarantee.
Connect the Water Inlet Attachment (6) with
Water Inlet Filter (6A) (Fig. 7).
Fig. 7
Connect your garden hose (female coupler)
to the Water Inlet (6) and turn on the water
tap (Fig. 8).
Fig. 8
To attach the Spray Lance, line up the locking tabs on the Lance with the slots in the Spray
Gun. Firmly push the Lance into the end of the Spray Gun, then turn clockwise to lock it in
place (Fig. 6). Make sure that the Lance is properly connected before using the pressure
washer. To remove the Spray Lance, press it down into the Spray Gun and turn it
anticlockwise to release.
Use the Turbo Lance when extra cleaning pressure is needed.
DO NOT USE THE TURBO LANCE ON PAINTED OR DELICATE SURFACES.
Fig. 6
Adjustable Spray Lance
Turbo Lance
