5
ASSEMBLY
Assemble all loose parts and attachments before using your machine for the first time:
Using the included screw, install the Spray
Gun holder (14) onto the main body as
shown in Fig 2.
If the High Pressure Hose Hook (8) is not
assembled, attach it to the back of the
Carry handle as shown in Fig. 3
Using the included screws, attach the
Stabilising Stands (18) as shown in Fig 4.
Fig. 2
Fig. 3
Fig. 4
Connect the High Pressure Hose to the
Spray Gun (10) by pressing the silver end of
the Pressure Hose into the connector on the
Spray Gun and screwing the nut on tightly
(Fig. 5).
It is recommended to lock the nut with pliers
or a wrench. Take care not to overtighten
the nut, or damage the nut with excessive
force.
Fig. 5
