Benning Tebevert 500 - Design of the Unit

Switch mode, single-phase, sine-wave Inverter
Product line TEBEVERT
August 8, 2005 - DTL 9/21 No. 4219en R2
3.1 Dimensions of the unit
Millimeter Inches
78 3.07”
275 10.82”
483 19”
466.2 18.35”
440 17.32”
88.1 3.47”
Fig. 2: Dimension diagram of the inverter
