Switch mode, single-phase, sine-wave Inverter
Product line TEBEVERT
August 8, 2005 - DTL 13/21 No. 4219en R2
3.3 Technical Data
DC input:
DC voltage: 24 VDC (48 VDC)
Permissible deviation from rated value: +20%; -15%
Input current at rated real power
Nominal input voltage 100%: 19.8 A (19.0 A)
Over voltage 120%: 16.3 A (16.0 A)
Under voltage 85%: 22.6 A (22.5 A)
Input current with no load and rated voltage: 1.0 A
Tolerated residual ripple on the input voltage: 5% rms
AC bypass input:
AC voltage: 120 VAC
Frequency: 60 Hz
AC Output:
AC voltage: 120 VAC
Static voltage tolerance: ±1%
(inverter operation)
Rated power (cosϕ=0.8): 0.5 kVA (1.0 kVA)
Rated active power: 0.4 kW (0.8 kVA)
Rated current (cosϕ=0.8): 4.2 A (8.3 A)
Short circuit behavior:
(DIN VDE 0100 - 410) >13A
rms
(>20A
rms
) for 40ms,
then switch-off
Overload behaviour: 2xI
N
for 4 s, then reduction to
1.2xI
N
for 60 s, then switch-off
Permanently tolerated overload: 1.1xI
N
