Switch mode, single-phase, sine-wave Inverter
Product line TEBEVERT
August 8, 2005 - DTL 12/21 No. 4219en R2
6 X5; potential free central fault signal
X5:1-2 fault
X5:1-3 no fault
7 X1(-); Copper bar / threaded stud; negative (-) connection for the DC
input of the inverter. Arranged for ¼” x 5/8”, two-hole crimp lug
8 threaded stud; frame ground connection, arranged for ¼” x
5/8”, two-hole crimp lug.
* 12033X-HW1
