2. Getting to know your monitor
Front view
Back view
Above diagram may vary depending on the model.
E2420HD
3 5 8
13
11
10
1 162 794
12
5
12
14
15
1. Speakers
2. AC Power Input jack
3. Line In and Line Out
4. Cable clip
5. HDMI socket x 2
6. DVI-D socket
7. D-Sub socket
8. USB port x 1 (upstream; connecting to the
PC)
9. Lock switch
10.USB port x 2 (downstream; connecting to
USB devices)
11.Headphone jack
12.USB port x 2 (downstream; connecting to
USB devices)
13.Headphone hook indicators (two inverted
triangles)
14.Control buttons
15.Power button
