22 How to adjust your monitor
8. How to adjust your monitor
The control panel
1. “Power”: Turn the power on or off.
2. “ENTER” key: Enter sub menus and select items.
3. t (Up) key: For Up/Increase adjustment. The key is also the hot key for Brightness.
4. u (Down) key: For Down/Decrease adjustment. The key is also the hot key for Contrast.
5. “MENU” key: Activate OSD main menu and return to the previous menu or exit OSD.
6. “Mode” key: Switch between different modes, including Standard, Movie, Dynamics, and
Photo.
7. “Input” key: Manually switch the input signal between D-Sub, DVI, and HDMI.
8. “
i
key”: Adjust vertical position, phase, horizontal position and pixel clock automatically.
OSD = On Screen Display.
The hot-keys will display a graduated scale for adjusting the value of that setting, and will only operate
while the OSD menu is not currently displaying. Hot-key displays will disappear after a few seconds of no
key activity. See Hot key mode on page 24.
