- 61 -
GL2055A Block Diagram
VGA
LED backlight Unit
30Pin
FFC
Auto Menu Left Right Enter Power
Interface
BD
Power
Board
AC in
GL2055 Block Diagram
VGA
LED backlight Unit
30Pin
FFC
Auto Menu Left Right Enter Power
Interface
BD
DVI
Power
Board
AC in
