5.4. Block diagram
GL2055 is a 20W” WXGA+ (1600x900) resolution TFT LCD monitor. The monitor
shall support VGA and DVI with HDCP inputs. It‟s compliant with VESA specification to
offer a smart power management and power saving function. It also offers OSD menu
for users to control the adjustable items and get some information about this monitor,
and the best function is to offer users an easy method to set all adjustable items well
just by pressing OSD auto-adjust function which can auto adjusting all controlled items.
GL2055 also offer DDC2BI function to meet VESA standard.
The GL2250 consists of a LCD module with LED BLU, a power board,
a control board, an interface board. The block diagram is shown as below.
The GL2250A consists of a LCD module with LED BLU, a power
board, a control board, an interface board. The block diagram is shown as
below.
The GL2250M consists of a LCD module with LED BLU, a power
board, a control board, an interface board ,a jack board and 1W speakers. The
block diagram is shown as below.
The block diagram is shown as below.
