BenQ GL2055 Product Service Manual

- 71 -
Appendix 1 – Screw List / Torque
STANDARD SCREW TORQUE SPEC for QCS
ITEM
P/N
DESCRIPTION
MOUNTING
MATERIAL
TORQUE
(KG-CM)
HOLE SIZE
(MM)
Screw
Head
1
8F.205B4.019
SCRW MACH HEX #4-40*0.3"
N
Metal;
D-SUB;DVI
Connector
5.0±0.6
5.0±0.6
#4-40
2
8F.5A224.6R0
SCRW MACH
FLATM3*0.5P*6L ZN
Metal
Metal to
metal
Plastic to
metal
Side mount:
3±0.6
Other: 4±0.6
M3*0.5
#2
3
8F.EA324.6R0
SCRW TAP FH M3*6L ZN
Metal
None tread： 8～
10
Have tread: 6～8
Φ2.68±0.03
#2
4
8F.5A356.8R0
SCRW MACH FH M4*8L B-ZN
NYL
Metal
Metal to
metal
Plastic to
metal
9.0±1.0
M4*0.7
#2
5
6K.L8810.001
ASSY SCREW M4*8L FP726A
NLK ISU
(8F.5A456.8R0+4B.L7212.001)
Metal
Metal to
metal
Plastic to
metal
9.0±1.0
M4*0.7
#2
6
8F.00273.6R0
SCRW TAP PH F/10WSH
M3*6L C-ZN
Metal
Metal to
metal
Plastic to
metal
PCB to
metal
None tread： 8～
10
Have tread: 6～8
Aluminum: 4~5
Æ 2.68±0.03
#2
7
8F.VZ524.6R0
SCRW TAP FLAT+EXT M3*6L
C-ZN
Metal
Metal to
metal
None tread： 8～
10
Have tread: 6～8
Aluminum: 4~5
No thread:6.5±0.5
(SGCC/SECC
0.5T)
Æ 2.68±0.03
#2
8
8F.00518.100
SCRW TAP W/FL
M3*10L(S3.8)ZN
Metal
Metal to
metal
Plastic to
metal
SPEAKER
to metal
None tread： 8～
10
Have tread: 6～8
Aluminum: 4~5
Æ 2.68±0.03
#2
9
8F.00003.143
SCRW TAP PAN #4-40*3/8
Aluminum
(Heatsink)
3.3±0.3
Φ2.6±0.03
#2
10
8F.VG234.6R0
SCRW TAP PH W/F M3*6 TP-
S ZN
Aluminum
(Heatsink)
None tread： 8～
10
Φ2.68±0.03
#2
