8F.VZ524.6R0

SCRW TAP FLAT+EXT M3*6L C-

6.5±0.5

(SECC/SGCC

0.5T)

8F.1A524.5R0

SCRW MACH PAN M3*5L NI

4.5±1.0

*SCREW QUANTITY & TYPE

AND POSITION

REFERRED TO Q328.

*NOTES:

1. (A)STANDARD SCREW

TORQUE SPEC.

2. (B)SPECIAL SCREW

TORQUE SPEC.

3. T: TAPPING SCREW.

4. M: MACHING SCREW.

D-SUB Connector

SCREW TORQUE SPEC.

SCREW TORQUE: 1.2±0.5 (KG-

CM)

DVI Connector

SCREW TORQUE SPEC.

SCREW TORQUE : 1.2±0.5

(KG-CM)

SCREW D-SUB

SCREW DVI
