Specifications 63
Supported timing for HDMI (HDCP) input - MP776
Supported timing for HDMI (HDCP) input - MP776 Supported timing for HDMI (HDCP) input - MP776
Supported timing for HDMI (HDCP) input - MP776
Displaying a 1080i(1125i)@60Hz or 1080i(1125i)@50Hz signal may result in slight
image vibration.
Resolution Mode
Vertical
Frequency (Hz)
Horizontal
Frequency (kHz)
Pixel
Frequency
(MHz)
720 x 400 720 x 400_70 70.087 31.469 28.3221
640 x 480
VGA_60 59.940 31.469 25.175
VGA_72 72.809 37.861 31.500
VGA_75 75.000 37.500 31.500
VGA_85 85.008 43.269 36.000
800 x 600
SVGA_60 60.317 37.879 40.000
SVGA_72 72.188 48.077 50.000
SVGA_75 75.000 46.875 49.500
SVGA_85 85.061 53.674 56.250
1024 x 768
XGA_60 60.004 48.363 65.000
XGA_70 70.069 56.476 75.000
XGA_75 75.029 60.023 78.750
XGA_85 84.997 68.667 94.500
1024 x 576 Netbook_timing 60.0 35.820 46.996
1024 x 600 Netbook_timing 64.995 41.467 51.419
1280 x 800
WXGA_60 59.810 49.702 83.500
WXGA_75 84.880 71.554 122.500
WXGA_85 74.934 62.795 106.500
1280 x 1024
SXGA_60 60.020 63.981 108.000
SXGA_75 75.025 79.976 135.000
SXGA_85 85.024 91.146 157.500
1280 x 960
1280 x 960_60 60.000 60.000 108.000
1280 x 960_85 85.002 85.938 148.500
1440 x 900
WXGA+_60 59.887 55.935 106.500
WXGA+_75 74.984 70.635 136.750
1400 x 1050 SXGA+_60 59.978 65.317 121.750
1600 x 1200 UXGA 60.000 75.000 162.000
640 x 480@67Hz MAC13 66.667 35.000 30.240
832 x 624@75 MAC16 74.546 49.722 57.280
1024 x 768@75Hz MAC19 75.020 60.241 80.000
1152 x 870@75Hz MAC21 75.060 68.680 100.000
Video (HDCP)
480p 60.000 31.470 27.000
576p 50.000 31.250 27.000
720p_60 60.000 45.000 74.250
720p_50 50.000 37.500 74.250
1080i_60 60.000 33.750 74.250
1080i_50 50.000 28.130 74.250
1080p 60.000 67.500 148.500
1080P 50.000 56.260 148.500
