BenQ MX720 - Page 2

Screen Size Distance from screen (in) Vertical
offset
(in)
Diagonal
W (in) H (in)
Min length
Average
Min length
Inch mm (Max zoom) (Max zoom)
40 1016 24 32 52.4 57.7 62.9 1.18
50 1270 30 40 65.6 72.1 78.7 1.49
60 1524 36 48 78.7 86.6 94.4 1.81
70 1778 42 56 91.8 101.0 110.2 2.08
80 2032 48 64 105 115.4 125.9 2.40
90 2286 54 72 118.1 129.9 141.7 2.71
100 2540 60 80 131.2 144.3 157.4 2.99
120 3048 72 96 157.4 173.2 188.9 3.58
150 3810 90 120 196.8 216.5 236.2 4.48
200 5080 120 160 262.4 288.7 314.9 5.98
250 6350 150 200 328.0 360.9 393.7 7.51
300 7620 180 240 393.7 433.0 472.4 9.01
Distance Chart
Wall Mount Chart
Dimensions
MX720 Digital Projector
4.09”
12.24”
9.6”
Unit: inch
Ceiling Mount screw: M4
(Max L = 25 mm; Min L = 20 mm)
The screen aspect ratio is 4:3
and the projected picture is 4:3
