BenQ TH530 User Manual (English)

Questions and Answers:

C
Carla HerringJul 29, 2025
Why my BenQ TH530 does not turn on?
- Y
  ywernerJul 29, 2025
  If your BenQ Projector is not turning on, it could be due to the following reasons: * There's no power from the power cord. Make sure the power cord is plugged into the AC power jack on the projector and into a working power outlet. If the power outlet has a switch, ensure it is switched on. * You're attempting to turn the projector on again during the cooling process. Wait until the cooling down process has completed.
J
Jeffrey WhiteAug 5, 2025
How to fix a BenQ TH530 Projector remote control that is not working?
- A
  Ashley WelchAug 5, 2025
  If the remote control for your BenQ Projector isn't working, consider these possible causes: * The battery is out of power. Replace the battery with new ones. * There is an obstacle between the remote control and the projector. Remove the obstacle. * You are too far away from the projector. Move closer, standing within 8 meters (26 feet) of the projector.
E
Eric ToddAug 14, 2025
What to do if my BenQ TH530 has no picture?
- C
  Carolyn OnealAug 14, 2025
  If your BenQ Projector is not displaying a picture, there are several potential causes: * The video source might not be on or properly connected. Ensure the video source is turned on and the signal cable is correctly connected. * The projector may not be correctly connected to the input signal device. Check the connection. * The wrong input signal might be selected. Use the SOURCE key on the projector or remote control to select the correct input signal. * The lens cover might still be closed. Open the lens cover.
L
Lauren CunninghamAug 20, 2025
How to fix a blurred image on a BenQ Projector?
- Y
  Yolanda ArellanoAug 20, 2025
  If the image from your BenQ Projector appears blurred, here are a few things to check: * The projection lens is not correctly focused. Adjust the focus of the lens using the focus ring. * The projector and the screen are not aligned properly. Adjust the projection angle and direction, as well as the height of the projector if necessary. * The lens cover is still closed. Open the lens cover.

BenQ TH530 Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	- m
Vertical scan range	23 - 120 Hz
Horizontal scan range	15 - 102 kHz
Projection technology	DLP
Contrast ratio (dynamic)	10000:1
Contrast ratio (typical)	-
Screen size compatibility	70 - 150 \
Projector native resolution	SXGA (1280x1024)
Keystone correction, vertical	-40 -40 °
Vertical synchronization (max)	0.12 kHz
Vertical synchronization (min)	0.023 kHz
Horizontal synchronization (max)	102 kHz
Horizontal synchronization (min)	15 kHz
Noise level	32 dB
Preset modes	3D, Cinema, Dynamic, Presentation, sRGB
On Screen Display (OSD)	Yes
Noise level (economic mode)	28 dB
On Screen Display (OSD) languages	ARA, BUL, CHI (SIMPL), CHI (TR), CRO, CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, IND, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR
Offset	115 %
Throw ratio	1.47 - 1.62:1
Focal length range	22 - 24.1 mm
Aperture range (F-F)	2.55 - 2.68
RMS rated power	2 W
Number of built-in speakers	1
Placement	Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Built-in display	No
Lamp power	196 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	10000 h
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	270 W
Power consumption (economy mode)	220 W
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Analog signal format system	NTSC, PAL, SECAM
Supported graphics resolutions	640 x 480 (VGA), 1920 x 1200 (WUXGA)
Cables included	VGA
Optical disc player type	Not included
Ethernet LAN (RJ-45) ports	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	222 mm
Width	283 mm
Height	95 mm
Weight	1960 g

Summary

Safety Instructions

Introduction

Projector Features

Details the various capabilities and technologies of the projector.

Shipping Contents

Lists all items included in the projector package.

Standard and Optional Accessories

Identifies included accessories and optional items for purchase.

Projector Exterior View

Controls and Functions

Projector Controls

Explains the buttons and indicators on the projector unit.

Remote Control Overview

Details the functions of each button on the remote control.

Remote Control Handling

Covers effective range and battery replacement for the remote.

Positioning Your Projector

Choosing an Installation Location

Guides on selecting the optimal placement for the projector.

Projected Image Size

Projection Dimensions Chart

Provides a table of screen sizes and corresponding projection distances.

Connecting Devices

Connecting Video and Audio Sources

Explains how to connect various video and audio input devices.

Projector Operation

Starting Up the Projector

Step-by-step guide to powering on the projector.

Adjusting the Projected Image

Covers angle adjustment, auto-image correction, and fine-tuning.

Correcting Keystone Distortion

Manual methods to fix image trapezoidal distortion.

Using OSD Menus

Explains navigation and basic settings via the On-Screen Display.

Securing the Projector

Details on using security cable locks and password protection.

Switching Input Signals

Guide to selecting and changing between different video sources.

Magnifying and Panning Image

Features for zooming into the image and navigating the zoomed view.

Selecting Aspect Ratio

Adjusting the image's width-to-height ratio.

Optimizing Image Appearance

Settings for Wall Color, Picture Mode, and User modes.

Fine-Tuning Image Quality

Adjustments for Brightness, Contrast, Color, Tint, Sharpness, and Brilliant Color.

Color Temperature and 3D Management

Settings for color temperature and 3D image adjustments.

Presentation Timer Setup

Configuring the on-screen timer for presentations.

Remote Paging and Image Freezing

Using remote for page control and freezing the projected image.

Hiding Image and Locking Controls

Features for blanking the screen and locking projector buttons.

High Altitude Environment Operation

Mode for operating the projector at higher altitudes.

Adjusting Sound Settings

Covers muting, volume, ring tone, and using the test pattern.

Using Teaching Templates

Utilizing built-in patterns for educational purposes.

Shutting Down the Projector

Procedure for turning off the projector and direct power off.

Menu System Overview

General structure and layout of the projector's OSD menu system.

Menu Descriptions: Display

Detailed explanation of the Display menu functions.

Menu Descriptions: 3D

Detailed explanation of the 3D menu functions.

Menu Descriptions: Picture & Source

Detailed explanation of Picture and Source menu functions.

Menu Descriptions: System Setup Basic

Detailed explanation of System Setup Basic menu functions.

Menu Descriptions: System Setup Advanced

Detailed explanation of System Setup Advanced menu functions.

Menu Descriptions: Information

Detailed explanation of the Information menu functions.

Maintenance

Projector Care and Cleaning

Instructions for cleaning the lens, case, and storing the projector.

Lamp Information and Life

Details on lamp usage, extending life, and modes.

Lamp Replacement Timing

Guidance on when to replace the projector lamp.

Replacing the Projector Lamp

Step-by-step procedure for replacing the lamp.

Resetting Lamp Timer

Procedure to reset the lamp usage timer after replacement.

Indicator Lights and Status

Explanation of the projector's indicator lights and their meanings.

Troubleshooting

Troubleshooting Common Issues

Solutions for common problems like no power, no picture, or blurred image.

Specifications

Projector Technical Specifications

Lists optical, electrical, mechanical, and control specifications.

Dimensions and Mounting

Provides physical dimensions and ceiling mount installation details.

Supported Input Timings

Details compatible PC, HDMI, Component, Video, and S-Video timings.

Warranty and Legal Information

Limited Warranty Details

Outlines the product's warranty terms, conditions, and limitations.

Copyright and Disclaimer

Legal notices regarding publication reproduction and product use disclaimers.
