TESTING
1) All the alarm sig nal ser vices, re leas ing de vice and ex tin guisher sys tem
should be dis en gaged dur ing the test pe riod and must be re-en gaged
im me di ately at the con clu sion of test ing.
2) Af ter en er giz ing the de tec tor head for ap prox i mately one min ute, check
to see the in di ca tor green LED flash ing once ev ery 3~5 sec onds. If
green LED fails to flash, it in di cates the non-func tion ing of the de tec tor
or faulty wir ing. Re-check the wir ing or re place the de tec tor if nec es sary.
3) Al low smoke from a cot ton wick or a test smoke aero sol to en ter the de -
tec tor-sens ing cham ber for at least 10 sec onds. When suf fi cient smoke
has en tered the cham ber, the de tec tor will sig nal an alarm, this be ing
vis i ble by a con tin u ous il lu mi na tion of the LED. Re set each de tec tor
and/or con trol unit be fore at tempt ing to test any ad di tional de tec tors in
the same zone. If the alarm fails in this step, it in di cates a de fec tive unit,
which re quires ser vice.
SPECIFICATION
http:www.ben tel se cu rity.com
MAINTENANCE
The rec om mended min i mum re quire ment for de tec tor main te nance con -
sists of an an nual clean ing of dust from the de tec tor head by us ing a vac uum
cleaner clean ing pro gram should be agreed to the in di vid ual environment.
+ CAUTION: DO NOT ATTEMPT TO DISASSEMBLY OF THE
FACTORY SEALED SMOKE DETECTOR. THIS ASSEMBLY IS
SEALED FOR YOUR PROTECTION AND IS NOT INTENDED TO BE
OPENED FOR SERVICING BY USERS. OPENING THE DETECTOR
HEAD WILL VOID THE WARRANTY.
RECYCLING INFORMATION
BENTEL SECURITY rec om mends that cus tom ers dis pose of their used
equipments (pan els, de tec tors, si rens, and other de vices) in an en vi ron -
men tally sound man ner. Po ten tial meth ods in clude re use of parts or whole
prod ucts and re cy cling of prod ucts, com po nents, and/or ma te ri als.
For spe cific in for ma tion see
www.bentelsecurity.com/en/en vi ron ment.htm
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)
DIRECTIVE
In the Eu ro pean Un ion, this la bel in di cates that this prod uct
should NOT be dis posed of with house hold waste. It should be
de pos ited at an ap pro pri ate fa cil ity to en able re cov ery and re -
cy cling.
For spe cific in for ma tion see
www.bentelsecurity.com/en/en vi ron ment.htm
BENTEL SECURITY s.r.l. re serves the right to change the tech ni cal spec i fi -
ca tions of this prod uct with out prior no tice.
LED
RELAY
JUMPER SETTING
SMOKE CHAMBER
FIG. 3 Sche matic of de tec tor struc ture
Model 2/4 wire Voltage DC
Standby
Current
(Max.)
Alarm
Current
(Max.)
Surge
Current
(Max.)
Start-Up
Time
(Max.)
Permissible
Current
(Max.)
Frequency
Alarm
contact
ZT100P 2 28/12 V
90 µA
50 mA
120 µA
60 s 80 mA 3-5 s
ZT100PL 2 28/12 V
90 µA
50 mA
120 µA
60 s 80 mA 3-5 s
ZT100PR1 4 12 V
320 µA
35 mA
120 µA
60 s 80 mA 3-5 s Form A
ZT100PR2 4 24 V
320 µA
35 mA
120 µA
60 s 80 mA 3-5 s Form A
