Berchtold Operon D820 - General Specifications

Kidney elevator (KIDNEY), (option-
al)
Split leg sections (SPLIT/LEG)
5.4 General information
NOTICE
All specifications refer to the OPERON® Surgical Mobile Operat‐
ing Table without a foot rest or split leg sections (optional).
Specification Value
Weight 606-725 lb. (275-329 kg)
Length 66.2-94.6 in. (1681-2389 mm)
Width (with side rails) 23 - 23.1 in. (583 - 587 mm) and 23.78
in. (604 mm) with rails
Width (without side rails) 21 in. (534 mm)
Height range 22.64-46.46 in. (575-1180 mm)
Specification Value
Length 14.17-14.49 in. (360-368 mm)
Width 21 in. (534 mm)
Specification Value
Length 21.69 in. (551 mm)
Width 21 in. (534 mm)
Specification Value
Length 21.06 in. (535 mm)
Width 21 in. (534 mm)
Head rest
Back section, long
Split back section (both
segments)
Operator Manual Surgical Mobile Operating Table Models D860, D850, D 830, D820, D770, D760
Technical Data
72
