Operation of Your Berchtold PodoS60 Spray Drill
1. Remove the Water Reservoir (3) and fill it with Distilled Water (ONLY USE DISTILLED WATER).
2. Place the Water Reservoir (3) in the Cavity (4) in the top of the Main Control Box and push it down
gently to ensure the pump inlet is fully inserted into the bottom of the Reservoir.
3. Insert your selected Burr into the Handpiece (2) (it will lock in automatically).
4. Turn the Master Switch (1) ON (the LCD Screen will illuminate and the default settings of Low Spray
volume and anti-clockwise Burr rotation will be shown).
5. If desired, change the burr direction by pressing Burr Direction Button (9) located on the Front Control Panel of the device.
WARNING: DO NOT change the Burr Direction when the Drill Burr is rotating as this will put the micro-motor
under extreme strain to change direction when rotating at up to 40,000 rpm.
6. Activate the Drill and Spray by pressing the Handpiece On/Off Button (14).
(NOTE: If the spray does not start operating within a few seconds when you first start the Drill, lower the
Handpiece close to the floor to allow gravity to assist with “priming” the empty spray lines).
7. Select the desired Burr speed by sliding your finger across the Burr Speed Control (7).
WARNING: If the burr being used has a head in excess of 5mm in diameter DO NOT operate the Drill at
more than 10,000 rpm.
8. If required, you can switch the Spray OFF by pressing the Spray On/Off Button (8).
9. You can increase or decrease the volume of spray required by pressing the Spray Volume
Setting Buttons (8).
10. When finished, switch the complete unit off at the Master Switch (1).
The Berchtold PodoS60 features the option to save preferred working settings (i.e: Burr Direction, Water Spray Strength & Burr
Speed) and to access them at the touch of a button. Follow the steps below to programme the three Memory Slots available:
1. Using the Burr Speed, Burr Direction and Water Level Buttons, adjust the drill to function at your desired
working setting.
2. Press and hold the Start/Stop Button (6).
3. Whilst holding the Start/Stop Button press the desired Memory Button (11) on the Front Control Panel.
4. Your preferred setting will now be saved to the Memory Button you have selected.
Programming Memory Slots
