Beretta Power Plus Box 1003 P INT User Manual

7
SYSTEM COMPONENTS
10
14
24
16 17
1
2
3
4
7
8
11
12
19
22
23
13
5
6
9
15
18
20
21
Figure 4
1 Frame
2 Control panel
3 Exchanger
4 Air inlet pipe
5 Fan
6 Return detection tap
7 Pump (or 2-way valve)
8 Unit Switch
9 Return probe
10 Exhaust flue probe
11 Water differential pressure switch
12 Gas valve
13 Ignition electrode
14 Automatic vent valve
15 Safety thermostat
16 Gas cock
17 Venturi tubes
18 Flow probe
19 Exhaust flue duct
20 Gas manifold
21 Water flow manifold
22 Condensate manifold
23 Water return manifold
24 Smoke-exhaust flue non-return valve

Beretta Power Plus Box 1003 P INT Specifications

General

Brand	Beretta
Model	Power Plus Box 1003 P INT
Category	Heat Pump
Language	English
