Bergey Powersync II - Inverter Specifications

Owner’s Manual BWC EXCEL 10 Turbine
Page 14
A. INVERTER SPECIFICATIONS
Input – From Turbine
Input Voltage Maximum (3 Phase Input)
400 VAC
Input Start Voltage Minimum
30 VAC
Input Operating Voltage Range
200 to 400 VAC
Input Frequency Maximum
400 Hz
Input Current Maximum
40 Amps
AC Backfeed Current to Input Source
N/A
Output – To Utility
Model
PSII12
PSII126208
Continuous Output Power Maximum
12000 KW
10400 KW
Continuous Output Power Tolerance
±10%
Output Voltage Nominal (Single Phase) Line-Line
240 VAC
208 VAC
Operating Voltage Range Line-Line
212-264
184-228
Output Voltage Nominal (Single Phase) Line-Neutral
120 VAC
Operating Voltage Range Line-Neutral
106-132 VAC
Continuous Output Current Maximum
50 Amps
Continuous Output Current Tolerance
± 10%
Voltage Measurement Tolerance
± 10 VAC
Operating Frequency Nominal
60 Hz
Operating Frequency Range
59.3 to 60.5 Hz
Operating Frequency Measurement Tolerance
± 0.5 Hz
Output Power Factor
0.95 ± 0.05
Temperature Range Normal Operation
-4°F to 113ºF (-20ºC to 45ºC)
Output Over-Current Protection Maximum
80 Amps
Synchronization In-Rush Current Maximum
6.3 Amps
Utility Interconnection Trip Time
100 msec
Time Measurement Tolerance
± 85 msec
B. Other Specifications
Dimensions
32.2”H x 24.3”W x 9” D
817 x 607 x 230 mm
Weight
153 lbs / 64 Kg
Enclosure
NEMA Type 1
NEMA 1 indicates that the enclosure is constructed for indoor use only. It provides
protection to personnel against incidental contact with the enclosed equipment.
