Bering BEXP25i - Electrical Wiring and Protection; Heat Pump Wiring Diagrams

21
NOTE
The factory supplies only the heat pump. All other components, including a bypass if necessary,
must be provided by the user or the installer.
6. Electrical Wiring
6.1 Swimming pool heat pump wiring diagram
Ref： BEXP05i/BEXP07i/BEXP09i/BEXP11i/BEXP14i/BEXP16i/BEXP18i/BEXP20i
