Mounting and Operation
The following table indicates the action objectives for mounting and operation of the power tool. The in-
structions for each action objective are shown aside. Depending on the type of application, various in-
struction combinations are required. Observe the safety instructions.
Action Figure Please observe Page
Selecting a drill chuck
(BHD-2/28 EC SDS+)
1 145
Removing the Quick Change
Chuck (BHD-2/28 EC SDS+)
2 146
Inserting the Quick Change
Chuck (BHD-2/28 EC SDS+)
3 146
Inserting SDS-plus Drilling
Tools
4 147
Removing SDS-plus Drilling
Tools
5 147
Inserting round shank applica-
tions tools
(BHD-2/28 EC SDS+)
6 148
Selecting the operating mode
and rotation direction
7 148
Changing the chisel position
8 149
Changing the position of the
auxiliary handle
9 150
Adjusting the drilling depth X
10 150
X
