Berner Multi HV-R User Manual

10
CHECK THE ACCURACY OF MULTI HV-R
1.AttachtheMultiHV-Ronatripodorhorizontalplanearound0.5m
parallelandperpendicularfromawallAand30metersawayfromawallB.
2.Makesurethatthesurfaceonwhichthelaserdeviceislocatedroughlyaligned.
3.TurnontheMultiHV-R.
4.Waituntiltheunithasitselfleveled.
5.MarkthepositionofthelaserbeamonthewallA.
6.Nowturnoverthelaser180°andmakeamarktotheoppositewallB.
7.Next,positionthedeviceabout0.5mfromthewallB.
8.Nowadjusttheheightofthelasersystemsothatthelaserbeamhitsthemark
exactly.
9.Nowturnoverthelaser180°andalignthelaserbeamonthewallA.Markthe
positionofthelaserbeamonwallA.
10.IfthemarksonthewallAmatchthelaserisdeviceoptimallycalibrated.
11.Shouldthemarkingsdisagree,measurethedifference.Todeterminetheaccuracy
ofsharingthevaluedeterminedbytwo.Thenewvaluecorrespondingtoa
measurementerrorofthedistancebetweenthetwowalls.Ifthevaluesexceed
2mmto10m,acalibrationisnecessary.
12.RepeattheaboveprocedurefortheYaxis.
13.Repeattheprocesswiththeunderlyingdevicefortheverticallaserline.
WARRANTY
Theunithas24monthswarrantyonmaterialandworkmanship.Warrantyonlytotheori-
ginalinvoice.Fordamagescausedbyuseofamisaligneddevice,noliabilityisaccepted.
Beforestartingwork,alwaysanaccuracytestshallbeperformedinaccordancewithsecti-
onstandingup!
ProducedforBernerTradingHoldingGmbH
Bernerstraße 6
D-74653Künzelsau

Berner Multi HV-R Specifications

General

Brand	Berner
Model	Multi HV-R
Category	Laser Level
Language	English
