BLADE RITE 1750 MANUAL
© Bernhard and Company Limited
Ref # Name of Part Qty. Part #
CARRIAGE
__________________________________________________________________
1 Carriage Base ......................................................................... 1 A4241
2 Carriage Deector Front.......................................................... 1 A6367
3 R.H. Inner Wiper Plate ............................................................ 1 A6368
4 Outer Front Wiper Plate ..........................................................2 A6369
5 Wiper Felt ................................................................................4 A6811
6 Eccentric Adjuster ................................................................... 2 A4223
7 Feedscrew ............................................................................... 1 A9150
8 Feedscrew Locking Bush ........................................................1 A9151
9 Bearing Spacer ....................................................................... 4 A9147
10 Bearing 628zz ......................................................................... 7 A7723
11 Feed Screw Handle 80mm...................................................... 1 A6154
12 Handle M6 x 20 dia ................................................................. 1
13 Handle M10 x 20 .....................................................................1 A6170
14 Hex Head Bolt M8 x 18 .......................................................... 2 A5731
15 Hex Head Bolt M8 x 20 .......................................................... 4 A5726
16 Button Head Screw M6 x 16 .................................................. 8 A5148
17 Button Head Screw M6 x 10 .................................................. 2 A5142
18 Brass Hex Set Screw M6 x 25 ................................................2 A5750
19 Brass Full Nut M6....................................................................2 A5528
20 Cap Head Socket Screw M3 x 12 ........................................... 4 A5181
21 Nut M3 ..................................................................................... 4 A5510
22 Cap Head Screw M6 x 60 ....................................................... 1 A5157
23 Washer M8 ..............................................................................2 A5321
24 D’Coil Spring Washer M10 ...................................................... 1 A5309
25 Washer M10 ............................................................................2 A5310
26 Washer M6 ..............................................................................1 A5320
27 Grub Screw M3 x 4.................................................................. 1 A5207
28 Traverse Motor 24v DC ........................................................... 1 A3396
29 Cap Head Screw M6 x 12 ....................................................... 2 A5171
30 Microswitch.............................................................................. 1 A8163
31 Slotted Pan Head Screw M3 x 20 .......................................... 2 A5430
32 Traverse Actuator Rod ............................................................1 A9148
33 Traverse Actuator Cone ..........................................................1 A9149
34 Traverse Rod Stop Collar ........................................................ 1 A9163
35 Socket Screw M5 x 6............................................................... 1 A5137
36 Socket Screw M6 x 6............................................................... 1 A5156
37 Clutch Shaft (Long) ................................................................. 1 A3391
38 Clutch Lever M10.....................................................................1 A6157
39 Clutch Eccentric ...................................................................... 1 A9159
40 Socket Screw M5 x 5............................................................... 1 A5137
41 Washer M10 ............................................................................1 A5310
42 D’Coil Spring Washer M10 ...................................................... 1 A5309
43 Nyloc Nut M10 ......................................................................... 1 A5505
44 Outer Rear Wiper Plate ........................................................... 2 A6370
45 L.H. Inner Wiper Plate.............................................................1 A6371
46 Nut M6 ..................................................................................... 1 A5516
47 Traverse Motor Bracket/Adaptor Plate (Not shown) ............... 1 A3394
9. Parts List (Continued)
