BLADE RITE 1750 MANUAL
© Bernhard and Company Limited
MOTOR PLATE AND TRANSMISSION
__________________________________
1 90 Degree Rotating Base........................................................1 A4245
2 Motor Transmission Housing................................................... 1 A4147
3 Index Mounting Plate............................................................... 1 A4151
4 Index Finger Block................................................................... 1 A4152
5 Index Finger c/w Roller ........................................................... 1 A3397
6 Blade Rest ............................................................................... 1 A4154
7 Cover for Index Mechanism .................................................... 1 A6373
8 Pin Lock Plate ......................................................................... 2
9 Stone Guard ............................................................................1 A6374
10 Stone Spacer for 6mm Stone..................................................1 A3387
10A Stone Spacer for 9.5mm Stone...............................................1 A3386
11 Grinding Wheel Spindle .......................................................... 1 A9152
12 Lobed Knob .............................................................................1
12A Locking Ring............................................................................ 1
12B Spacer .....................................................................................1
13 Bearing Housing......................................................................2 A9153
14 30 tooth Pulley 60Hz (Driven) .................................................1 A7214
15 40 toothed Pulley (Drive) ........................................................ 1 A7210
16 Drive Belt 5mm x 16mm x 420mm ..........................................1 A7108
17 Bearing 6003 2RS...................................................................2 A7726
18 Main Motor 60Hz single phase ...............................................1 A6006
Main Motor 50Hz single phase ...............................................1 A6004
Main Motor 50 / 60Hz 3 phase................................................1 A6005
19 Motor Cover Plate ...................................................................1 A6446
20 125 x 6mm Stone ....................................................................1 A3382
20A 125 x 9.5mm Stone .................................................................1 A3383
21 Shoulder Screw M8 x M6 x 12 ................................................ 3 A5165
22 Upper Height Adjust Boss .......................................................1 A3393
23 Wing Knob M6 x 15 ................................................................. 1 A6129
24 Height Adjust Stud................................................................... 1 A3390
25 Lower Height Adjust Stud........................................................ 1 A3389
26 Button Head Screw M5 x 25 ................................................... 2 A5169
27 Button Head Screw M5 x 16 ...................................................6 A5133
28 Button Head Screw M8 x 16 ................................................... 4 A5813
29 Cap Head Socket Screw M6 x 12 ........................................... 2 A5171
30 Cap Head Socket Screw M5 x 6 ............................................. 4 A5139
31 Nylock Nut M5 ......................................................................... 2 A5513
32 Index Finger Spring ................................................................. 1 A6814
33 Spring .....................................................................................2 A6908
34 Button Head Screw M5 x 6 .....................................................2 A5139
35 Socket Grub Screw M4 x 6 .....................................................4 A5190
36 Washer M6 ..............................................................................2 A5320
37 Washer M5 ..............................................................................3 A5318
38 Button Head Screw M5 x 10 ...................................................1 A5129
39 Transmission Cover Guard .....................................................1 A6372
40 Button Head Screw M3 x 10 ...................................................2 A5187
Junction Box Assembly (Not shown) ......................................1 A3403
9. Parts List (Continued)
Ref # Name of Part Qty. Part #
