Attention: Turn the power switch off and
wait until the lamp has cooled down before
touching it.
Loosen the screw (a) on the left side of the
sewing head and remove the face plate (b).
(1)
Pull light bulb downward to remove.
Replace the bulb with same type rated
5w/12V.
Set the face plate and tighten the screw. (2)
Light bulb replacement
