Table 7.09 - Output Options Table
Option & description
Option & description
[ 0 ]
Output is disabled
[32]
Alarm form Input 2: Shutdown/Warning
[ 1 ]
Under Frequency Shutdown
[33]
Alarm form Input 3: Shutdown/Warning
[ 2 ]
Over Frequency Shutdown
[34]
Alarm form Input 4: Shutdown/Warning
[ 3 ]
Over Current Shutdown
[35]
Cumulative Oil Alarms
[ 4 ]
Over Current Warning
[36]
Cumulative Temperature Alarms
[ 5 ]
Overload Warning or Shutdown (^^^)
[37]
Cumulative Alternator Alarms
[ 6 ]
Over Voltage Shutdown
[38]
Common Fuel Alarms
[ 7 ]
Under Voltage Shutdown
[39]
Horn Output (See table 7.05 [P50])
[ 8 ]
Alternator Failure Shutdown
[40]
Crank Delay (Start Warning)
[ 9 ]
Low Oil Pressure Warning
[41]
Presence of Nominal Mains Parameters
[10]
Low Oil Pressure Shutdown
[42]
Mains Failure Timing
[11]
Oil Sender Failure Warning
[43]
Mains Restore Timing
[12]
High Temperature Warning
[44]
KG Status
[13]
Temperature Switch Shutdown
[45]
KM Status
[14]
Temperature Sender Failure Warning
[46]
Pre-glow MODE 1/2/3/4
[15]
Low Battery Voltage Warning
[47]
PURGE (gas engine valve control)
[16]
High Battery Voltage Warning
[48]
RENT<48h
[17]
Low Fuel Shutdown (switch)
[49]
RENT=0h (Expired)
[18]
Fuel Low Warning (sensor)
[50]
Engine Running Status
[19]
Fuel Reserve Warning (switch)
[51]
Presence of Nominal Generator Voltage
[20]
Fuel high Warning (sensor)
[52]
BE42 in OFF MODE (Status)
[21]
Fuel Sender Failure Warning
[53]
BE42 in MANUAL MODE (Status)
[22]
Emergency Stop Shutdown (Er08)
[54]
BE42 in AUTO MODE (Status)
[23]
Stop Pushbutton Used in AUTO (Er09)
[55]
BE42 in TEST MODE (Status)
[24]
Maintenance SERVICE 1 (Er10)
[56]
BE42 in LOCK MODE (Status)
[25]
Maintenance SERVICE 2 (Er10)
[57]
Be42 runs the Automatic Periodic Test
[26]
Maintenance SERVICE 3 (Er10)
[58]
Cooling Timing
[27]
Engine Belt Break Shutdown
[59]
Warm up Timing
[28]
Fail To START Shutdown
[60]
Cycling mode (Logical OR of engine running
and stop solenoid)
[29]
Fail To STOP Shutdown
[61]
Start Pilot repeat output (it repeats the crank
output terminal #9)
[30]
Indication of Parameter Error warning
-
--
[31]
Alarm form Input 1: Shutdown/Warning
-
--
(^^^) If an input is configured with option [20] or [21] (see table 7.07)
Table 7.10 - Oil Pressure Sensor Settings
Display
Parameter
Default
Range
[Pr.1]
Pressure
[ 0.0] Bar
0 up to 20 Bar
0 up to 2000
Ohm
[-r1-]
Resistance
[ 10] Ohm
[Pr.2]
Pressure
[ 2.0] Bar
[-r2-]
Resistance
[ 51] Ohm
[Pr.3]
Pressure
[ 4.0] Bar
[-r3-]
Resistance
[ 86] Ohm
[Pr.4]
Pressure
[ 6.0] Bar
[-r4-]
Resistance
[ 122] Ohm
[Pr.5]
Pressure
[ 8.0] Bar
[-r5-]
Resistance
[ 152] Ohm
[Pr.6]
Pressure
[ 10.0] Bar
[-r6-]
Resistance
[ 180] Ohm
