Section 21.0: Connections description
Terminal
Description
Note
Section
1
Generator Contactor output
300mA Active 'Low'
2.21
2
Mains Contactor output
3
Programmable output „4‟
7.09
4
Programmable output „3‟
5
Programmable output „2‟
6
Programmable output „1‟
7
Fuel Solenoid output
18.0
8
Stop Solenoid output
9
Crank Pilot output
10
Alternator Excitement output
Positive Output 3W
11.0
11
Current Transformer „L1‟ S1 input
5Aac nominal; Max 8Aac
7.02B
([P.18])
12
Current Transformer „L1‟ S2 input
13
Generator Voltage‟ Phase L1‟ input
600Vac rated
7.02B
14
Not connected
15
Generator Voltage „Phase L3‟ input
16
Mains Voltage „Phase L3‟ input
7.01A
17
Not connected
18
Mains Voltage „Phase L2‟ input
19
Not connected
20
Mains Voltage‟ Phase L1‟ input
21
Engine Running Minus detect
Connect to ground
11.0
22
Engine Running Plus detect
D+ or W.L. sensing
23
Supply Battery minus connection
-
14.0
24
Supply +12 or +24V Battery connection
Internal 300mA fuse
25
Common Sender ground sense
-
19.0
26
Fuel Level Sender input
2000 Ohm max
7.12
27
Temperature Sender input
7.11
28
Oil Pressure Sender input
7.10
29
Programmable input Switch '4'
Active Low (<2Vdc)
7.07
30
Programmable input Switch '3'
31
Programmable input Switch '2'
32
Programmable input Switch '1'
33
Low Fuel Switch input
18.0
34
High Temperature Switch input
35
Low Oil Pressure Switch input
36
Emergency Stop Switch input
37
RS485 Termination
See RS485 standard
See Be42
MODBUS
user manual
38
RS485 Signal A
39
RS485 Signal B
40
RS485 Common Ground
!! W A R N I N G !! Relays and solenoids connected to the Be42 must be suppressed
using flywheel diodes or suppression devices as indicated in section 18.0. We
recommend that you connect a 1A Fuse (fast BLOWING) in series to the terminal #24;
it will protect the controller against large spikes on the power supply.
