Section 4.0 Display messages and LOG Events
The Be42 shows alarms (table 4.10) and messages (table 4.20). The presence of alarms is indicated by the
blinking message [ ALAr.]. Push the [→F9] pushbuttons to display the alarms one by one. Push the [←F8]
pushbutton to display additional information (section 8.0).
Table 4.10: Alarm messages
Display
Message
Description of the Alarm
Display
Message
Description of the Alarm
[Er.01]
Over Frequency Shutdown (see [P.12])
[Er. 14]
Low Oil Pressure Shutdown
(Pressure switch connected to input #35)
[Er.02]
Engine Belt Break Shutdown (see [P.26])
[Er. 15]
Temperature Switch Shutdown
(Temperature switch connected to Input #34)
[Er.03]
Remote LOCK Shutdown (see 7.07 option
[13])
[Hi-C]
Over Current Shutdown or Warning (see
[P.13]).
[Er.04]
Alternator Failure Shutdown
[Hi-U]
Over Voltage Shutdown (see [P.10])
[Er.05]
Overload Warning (see 7.07 option [20])
[Lo-U]
Under Voltage Shutdown (see [P.09])
[Er.05]
Overload Shutdown (see 7.07 option [21])
[InP.1]
Input 1 Shutdown / Warning (see 7.07)
[Er.06]
Under Frequency Shutdown (see [P.11])
[InP.2]
Input 2 Shutdown / Warning (see 7.07)
[Er.07]
Fail To STOP Shutdown (see parameter
P.34, section 7, table 7.04)
[InP.3]
Input 3 Shutdown / Warning (see 7.07)
[Er.08]
Emergency Shutdown (see paramter
P.35, section 7, table 7.04)
[InP.4]
Input 4 Shutdown / Warning (see 7.07)
[Er.09]
Emergency Shutdown triggered by Front
Panel (Stop or [0] pushbutton)
[-oIL]
Oil pressure warning or sensor failure. Push
[←F8] to display the value (see P29).
[Er.10]
Maintenance SERVICE warning
(see parameters P44,P45 and P46)
[ -°C]
Water temperature warning or sensor failure.
Push [←F8] to display the value (see P30).
[Er.11]
Fail To START Shutdown
[FUEL]
Fuel level warning (High or Low) or sensor
failure. Push [←F8] to display the value.
[Er.12]
Low Fuel Shutdown (If Low Fuel input,
terminal #33, is activated for longer than
the P.36 time. See Table 7.04A)
[rEnt]
The rental contract is going to expire (48
hours remaining). Push [←F8] to display the
value.
[Er. 13]
Battery Voltage Warning. Push [←F8] to
display the value.
[FAIL]
There is an internal failure or memory error in
the BE42 controller (see 12.3)
4.20 Miscellaneous [messages] & description
[rESt]
The Be42 is counting the rest time between the
starting attempts
[ProG]
The Be42 is in program mode
[n-on]
MAINS Simulated by an input (see option [15] in
the table 7.07).
[-CAL]
The Be42 is in calibration mode
[. . . .]
The Be42 is cranking the engine
[ ' ' ' ' ]
The Be42 is performing the pre-glow (P22)
[tEst]
The Be42 is in Test mode
[StoP]
The Be42 is stopping the engine (P25)
[ - - - - ]
Measurement out of range or disabled
[U-uP]
Warm up time of the engine before closing the
contactor of the generator (P23).
[CooL]
The engine is running off load for
cooling.
[ dEL]
Delay time before cranking (P.19,table 7.03A)
