10
install the door racks to
Connecting the Water Supply
An Ice Maker and/or water filter may be
installed on your new refrigerator. A water
filter removes unwanted particles from
your water. It does not, however, sterilize
or destroy microorganisms. For
purification and sterilization, it may be
necessary to purchase a water purifying
system.
For the ice maker to operate properly, The
appliance must be connected to a
drinking water supply and ensure the
water pressure is between 30 to 125 psi.
The water connection must be carried out
by a qualified plumber. Operation outside
the water pressure range may cause
malfunction and severe, damaging water
leaks.
Under normal conditions, a 200cc (5.75
oz.) cup can be filled in about 10 seconds.
If the refrigerator is installed in an area
with low water pressure (below 30 psi), a
booster pump may be installed to
compensate for lower inlet pressures.
The following tools and parts will be
needed:
(Not supplied ):
Important:
Use tubing supplied with the refrigerator
and/or all new tubing. Do not use old
tubing.
1- All work must comply with local
plumbing code specifications and
requirements.
2- Connect to cold water line with
water pressure between 30 and
125 psi.
3- Take caution to not contaminate
water pipes. The size of pipes is
1/4".
4- The product comes with the filter.
Please connect the water filter
referring to the filter instructions.
Connecting the Water Supply
1- Shut off power supply.
2- Shut off water main supply.
3- In the cold-water supply line, drill a
¼” hole in the vertical section or
horizontal (top of pipe). Then
install the saddle-type shutoff
valve. Ensure the outlet end is
firmly in the ¼” hole.
4- Securely connect the ¼” extension
To Next Page
