10
The duster’s identification plate is located on the front left-hand side of the chassis.
The reference in the "Type" box is composed of letters and numbers.
Example : 8 AP OL 600 = Apolo 600
06 = Tank capacity 600 litres
AP OL = Apolo (basic model)
8 = duster (product familly)
DESCRIPTIVE PLATE
The "Kerb weight" and "Gross vehicule
weight" boxes use the data in the table on
page 1.
Manufacturing year
The "Serial No." box is composed
of 8 figures
Example : 95 1042 04 = serial number
Z.I. de Bois Baron
1, rue de l'industrie
69220 BELLEVILLE S/S - FRANCE
