15
OPERATION
FILLING HOPPER :
Make sure that no foreign body (bag fragments or
others) are mixed with the powder.
ADJUSTING FLOW DIVIDER :
Act on the knurled knob (1) (figure 7) of the divider
as indicated on the flow table (page 17).
7
9
8
START OF DUSTING OPERATION :
Engage the power take-off (540 rpm).
Switch on the hyraulic circuit using the distributor
of your tractor.
All that needs to be done, at the end of each row,
in order to initiate or stop dusting, is to switch off
and then switch on your distributor.
DUSTING ON ONE SIDE ONLY :
Disengage the archemedians screw on the side
opposite that you wish to dust. Loosen the nut (1),
lift the protective cover (2), then pull the knurled
knob (3) (figure 8) toward the front of the duster.
ADJUSTING THE BLADES :
Before dusting, adjust the output blades and their
tubes (figure 9).
AT THE END OF THE TREATMENT, EMPTY
THE HOPPER BY USING THE TWO
ARCHEMEDIANS SCREW.
CLEAN THE HOPPER.
1
1
2
3
