- 11 -
FIGURE 20
CHARCOAL
FILTER
WIRE
RETAINERS
NON-DUCTED
RECIRCULATION
FILTERS INSTALLATION
(NON-DUCTED HOODS ONLY)
Non-ducted recirculation filters are
included with kit ANKCC45.
1. Replacement non-ducted
recirculation filters can be
purchased separately
(AECC45SB).
2. Position the non-ducted
recirculation filter over the grease
filter and block it by means (2) wire
retainers. Refer Figure 20.
