Ducting Configurations (continued)
Planning
Front Exhaust with Flex Blower (through cabinet)
Wiring Box
Downdraft
PF6 (Flex Blower)
8
"
Straight Duct
8
"
Round Elbow
*To Model 643 (8" Round Wall Cap)
*
Downdraft
Wiring Box
ANKD (Recirculation Kit)
PF6 (Flex Blower)
8
"
Straight Duct
Front Exhaust with Flex Blower and
Recirculating Kit
Front Exhaust with Flex Blower (through
cabinet) and Recirculating Kit
Wiring Box
Downdraft
PF6 (Flex Blower)
8
"
Straight
Duct
8
"
Round Elbow
ANKD (Recirculation Kit)
To Next Page
