MODEL iQ6
Page 3
INSTALLATION
1. Run power cable to installation location.
2. Remove one electrical knockout from rough in plate wiring
box.
VERTICAL DISCHARGE
(UP26M, UP27M, WP28M, WP29M, IP29M)
HORIZONTAL DISCHARGE
(WP28, WP29)
3. Attach rough in plate to mounting studs at inside of hood
with (4) existing 10-32 Hex Nuts.
REMOVE ONE
ELECTRICAL
KNOCKOUT
